The hand-held fan is compact and portable. It can be used at home or on travel. It is convenient to carry and does not take up space. It is a must-have artifact for home travel and is deeply loved by the public. However, in general, PSE certification is required for such products to be exported to the Japanese market.
What is PSE certification?
PSE certification is a Japanese compulsory safety certification, which is used to prove that electrical and electronic products have passed the safety standard test of the Japanese Electrical and Material Safety Law or the international IEC standard. Japan's DENTORL Law (Electrical Device and Material Control Law) stipulates that 498 products must pass safety certification to enter the Japanese market. Among them, 165 types of A products should obtain the diamond-shaped PSE mark, and 333 types of B products should obtain the round PSE mark.
Type A compulsory certification: special electrical equipment and material products
Type B compulsory certification: other electrical equipment and material products
Handheld fan PSE certification based on standards
J60335-1 (H27) "Safety of Household and Similar Electrical Appliances Part 1: General Requirements"
J60335-2-80 (H20) "Safety of Household and Similar Electrical Appliances Part 2-80: Particular Requirements for Fans"
Handheld fan PSE certification test items
1. Signs and instructions; protection against contact with live parts;
2. Starting of electric appliances; input power and current;
3. Heating; leakage current and electric strength at working temperature;
4. Moisture resistance; leakage current and electric strength;
5. Overload protection of transformers and related circuits; abnormal operation;
6. Stability and mechanical hazards; mechanical strength;
7. Structure; internal wiring; power connection and external cord;
8. Terminals for external wires; grounding measures; screws and connections;
9. Electric clearance, creepage distance and solid insulation;
10. Heat and flame resistance; anti-rust.
Information to be prepared for PSE certification application for handheld fan
1. PSE certification application form; CB report (including Japan's difference test);
2. Circuit diagram; PCB design diagram and structure data sheet related to safety regulations;
3. Specifications of transformers and coil parts; list of key components and certificates;
4. Japanese user manual or assembly manual; Japanese label (including PSE mark and notification of the supplier's name);
5. Appearance photos inside the product; factory inspection documents; other required documents.
Handheld fan PSE certification process
1. Application;
(1) Fill in the application form
(2) Application company information form
(3) Provide product information and send samples
2. Quotation. According to the information provided, ZRLK engineers determine the test standards, test time and corresponding costs;
3. Payment. After the applicant confirms the quotation, sign the application form and service agreement and make payment;
4. Test. The laboratory conducts a full set of tests on the applied products according to relevant testing standards;
5. The test is passed and the report is completed;
6. The project is completed and a certificate is issued.
For handheld fan PSE certification, please contact our company ZRLK, we will provide you with professional and efficient testing and certification services, preferential prices and courteous service. If you provide us with product pictures and specifications, we will give us the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
